| Image Sensor: | 1/3''Cmos 4MP CMOS |
| Signal System: | PAL/NTSC |
| Min. Illumination: | Color: 0.05lux @(F1.6, AGC ON), 0 lux with IR |
| Shutter Time: | 1/25 s to 1/100,000 s |
| Lens: | 3.6mm F1.6 Fixed Lens (2.8mm Optional) |
| Day&Night: | 2pcs Homologous Dual Light (Warm Light+IR LED Light) |
| Image Enhancement: | BLC/3D DNR/D-WDR |
| Motion Detection | Support |
| Privacy Protection | Support(4 Self-customized Areas) |
| Water-Proof: | IP66 |
| Illumination for Infrared Switching: | 0.5~3Lux |
| Infrared Wavelength: | 850nm |
| Mimimum Illumination: | 0 Lux(IR ON or Warm Light ON) |
| LED Light Distance | IR 25m/Warm light 20m |
| Smart function: | Humanoid detection,video cover. |
| Compression Standard | |
| Video Compression: | H.265/H.264/MJPEG |
| Video Bit Rate: | 512Kbps~12288Kbps(main stream H.265) 64kbps~512Kbps(sub stream H.265) 64kbps~1024kbps(third steam H.265) |
| Dual Streams: | Yes |
| Triple Streams: | Yes |
| Image | |
| Image Resolution: | main stream:3840*2160(8MP)/2592x1955(5MP)/2560x1440(4MP)/1080P sub stream:720x480(D1)/640x480(VGA)/640x360/352x288(CIF) thrid stream:1080p/720p/CIF |
| Frame Rate: | main stream:20fps（3840*2160）8MP/60fps(1080p) sub stream:30fps thrid stream:5fp |
| Stream: | Triple streams |
| Image Settings: |
3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App |
| Day/Night Switch: | support Full color mode，auto switch mode（BW with IR led）,trigger mode(Humanoid triggers white light at night） |
| Audio | |
| Audio Compression: | G711U/G711A/AAC |
| Audio Bitrate | 64K(G711)/16k(AAC) |
| Audio In/Out： | Optional (RCA socket) |
| Build-in MIC： | Optional |
| Volnume adject： | Yes |
| Network | |
| Network Protocols: | HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, RTMP,DDNS, IP Search(Support Danale IP camera, DVR, NVS etc.) |
| General Function: | Anti-Flicker, heartbeat, password protection, privacy mask, Watermark |
| System Compatibility: | ONVIF(17.2 with profile S) |
| On-line Viewing | Max. Support 2 Users Simultaneously |
| Interface | |
| Communication Interface: | 1 RJ45 10M / 100M Ethernet Interface |
| Audio Interface: | RCA Audio input/output Interface (Optional) |
| Alarm in/out interface： | Support（1ch） （Optional） |
| SD card interface | Support TF card（micro TF card，up to 128G） （Optional） |
| DC Power Plug: | DC Power Femate Interface/POE(optional) |
| General | |
| Operating Conditions: | -10 °C ~ 60 °C |
| Humidity 95% or less (non-condensing) | |
| Power Supply: | 12 V DC ± 10%/PoE(Optional) |
| Power Consumption: |
12 VDC ± 10%, Max Power Comsumption Less than 8W (When the infrared lamps turn on) |
| Weight: | 0.56KG |
