CAMERA | |
Image Sensor | 8MP 1/2.8" Sony CMOS Sensor |
Min. Illumination | Normal Model |
White Balance | Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
Gain | Auto/Manual |
Shutter Time | 50Hz |
Day & Night | Normal or ColorVu |
Privacy Mask | 4 programmable privacy masks |
Lens | |
Focal Length | 2.8 mm (3.6mm Optional)Horizontal field of view |
Field of View | Vertical field of view |
Compression Standard | |
Video Compression | Main Stream |
H.264 Type | Baseline profile/main profile/high profile |
Event | |
Basic Event | Motion Detection |
IR | |
IR Distance | IR LEDs up to 50m |
IR LED | 4PCS |
Image | |
Max. Resolution | 2MP |
Main Stream | 2MP |
Sub-Stream | 2MP |
Image Enhancement | 3D DNR, EIS, Regional Exposure, Privacy Mask, Mirror |
Network | |
Ethernet | RJ-45 (10/100Base-T) |
Protocols | IPv4/IPv6, HTTP/RTSP/NFS/SMTP/DHCP/NTP/TCP/IP, etc. |
API | ONVIF (Profile S, Profile G, Profile T),HIKVISION |
Simultaneous Live View | Up to 20 channels |
Client | SADP, Danale, Blue Iris , ISpy |
Web Browser | IE 8 to 11,Chrome 31.0+, Firefox 30.0+, Edge 16.16299+ |
Interface | |
Network Interface | 1 RJ45 10 M/100 M Ethernet, PoE |
Power | |
12 VDC or POE | |
General | |
Language (Web Browser Access ) | 7 languages |
Power | 12 VDC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR);PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR) |
Working Environment | Temperature |
Protection Level | IP66 standard |
Material | Aluminum alloy |
Dimension | Φ 65 mm × 190 mm |
Weight | Approx. 0.45 kg |
