| Camera | |
| Image Sensor | 2MP: 1/2.7” Sony Sensor |
| 5MP: 1/2.8" Sony Sensor | |
| 8MP: 1/2.8" Sony Sensor | |
| Min. Illumination | 24/7 full time color |
| White Balance | Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp |
| Gain | Auto/Manual |
| Shutter Time | 50Hz: 1/25 s to 1/100,000 s |
| Day & Night | N |
| Privacy Mask | 4 programmable privacy masks |
| Lens | |
| Focal Length | F1.0 3.6mm (6mm Optional) |
| Field of View | Horizontal field of view: 103° Vertical field of view: 69° Diagonal field of view: 110° |
| Compression Standard | |
| Video Compression | Main Stream: H.265/H.264 Sub-stream: H.265/H.264 |
| H.264 Type | Baseline profile/Main profile/High profile |
| Event | |
| Basic Event | Motion Detection |
| LED | |
| White Light Range | Warm white LEDs, up to 30m |
| White Light | 4 pieces |
| Image | |
| Max. Resolution | 2MP: 1920 × 1080 |
| 5MP: 2592 × 1944 | |
| 8MP: 3840 x 2160 | |
| Main Stream | 2MP: 25fps 2MP(1920x1080)/720P |
| 5MP: 15fps 5MP(2592 × 1944),20fps 4MP(2560x1440)25fps 3MP/2MP/720P | |
| 8MP: 20fps 8MP(3840 x 2160,25fps 6MP(3072x2048)30fps 5MP/4MP/3MP/2MP/720P | |
| Sub-Stream | 2MP: D1/VGA/640x360/CIF 30fps, etc |
| 5MP: D1/VGA/640x360/CIF 25fps, etc | |
| 8MP: VGA/640x360/480X360P/CIF 25fps, etc | |
| Image Enhancement | 3D DNR, EIS, Regional Exposure, Privacy Mask, Mirror |
| Network | |
| Ethernet | RJ-45 (10/100Base-T) |
| Protocols | IPv4/IPv6, HTTP/RTSP/DHCP/NTP/TCP/IP,etc. |
| API | ONVIF (Profile S, Profile G, Profile T),HIKVISION |
| Simultaneous Live View | Up to 20 channels |
| Client | SADP, Danale, Blue Iris, ISpy |
| Web Browser | IE 8 to 11,Chrome 31.0+, Firefox 30.0+, Edge 16.16299+ |
| Interface | |
| Network Interface | 1 RJ45 10 M/100 M Ethernet, PoE |
| Power | 12V DC / PoE |
| General | |
| Language (Web Browser Access ) | 7 languages: Chinese, English, Russian, German, Italian, Turkish, 한국어 |
| Power | 12 VDC, 1.5 A (Max. 10.9 W, including Max. 4.2 W for IR) |
| PoE (802.3af), 36 to 57 VDC, 0.35 A (Max. 12.2 W, including max. 4.2 W for IR) | |
| Working Environment | Temperature: -20°C to 60°C (-4°F to 140°F), humidity: ≤ 90% |
| Protection Level | IP66 standard |
| Material | Aluminum Alloy |
| Dimension | Φ 260mm × 140mm x 130mm(Φ 5.5" × 5.11") |
| Weight | Approx. 0.9 kg (1.99 lb.) |
