Megapixel IP Mini Vandal Dome CCTV Camera Bus Elevator Security Camera

Product Item：GW-IP2525MC-I

• H.265/H.264 2MP IP/Network IR Mini Vandal Dome Camera
• Up to 2 megapixel high resolution
• Max. 1920*1080@30fps(50Hz/60Hz)
• Support RTSP&Onvif(17.2 with profile S)
Compatible with many third-party NVRs and CMS
• Support multiply Web Browsers: IE/Firefox/Chrome/Safari etc.
• P2P Cloud service
• Free PC Client Software and Smartphone APP(P2P)
• Support Alarm Snapshot to Email and FTP
• Day/Night, AWB/MWB,BLC, 3D-DNR,Shutter, IR-CUT,
D-WDR,Mirror, Image Flip etc. Functions
• Audio in/out Optional(RCA Cable Interface)
• 12V DC (PoE Optional)
• 2.8mm fixed lens
• IR range: up to 12m
• Water-proof: IP66
• Hikvision/Dahua protocol Optional

Image Sensor:	1/2.8'' Sony307 2MP CMOS
Signal System:	PAL/NTSC
Min. Illumination:	Color: 0.05lux @(F1.2, AGC ON), 0 lux with IR
Shutter Time:	1/25 s to 1/100,000 s
Lens:	3.6mm fixed lens
Day&Night:	IR cut filter with auto switch
Image Enhancement:	BLC/3D DNR/D-WDR
Motion Detection	Support
Privacy Protection	Support(4 Self-customized Areas)
Water-Proof:	IP66
Illumination for Infrared Switching:	0.5~3Lux
Infrared Wavelength:	850nm
Mimimum Illumination:	0 Lux(IR ON)
IR Range:	12pcs LEDs//12m IR
Compression Standard
Video Compression:	H.265/H.264/MJPEG
Video Bit Rate:	32Kbps~12288Kbps(CBR/VBR Selectable)
Audio Compression:	G711U/G711A
Dual Streams:	Yes
Triple Streams:	No
Max. Image Resolution:	1920*1080@30fps(2MP)
Frame Rate:	50/60Hz: Max.: 1920*1080@30fps
Sub Stream:	50Hz/60Hz: Max. (800488/704576/640360/352288)@30fps
Third Stream(Mobile Stream):	/
Image Settings:	3D NR, D-WDR, Image Flip, Saturation, Brightness, Contrast, Sharpness adjustable via client software, web browser or Smartphone App
Day/Night Switch:	Auto(Passive Mode)/Day/Night/Auto(Active Mode)/Time
Network
Network Protocols:	HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, IP Search(Support Danale IP camera, DVR, NVS etc.)
General Function:	Anti-Flicker, heartbeat, password protection, privacy mask, Watermark
System Compatibility:	ONVIF(17.06 ) profile S/Danale(P2P)
On-line Viewing	Max. Support 6 Users Simultaneously
Interface
Communication Interface:	1 RJ45 10M / 100M Ethernet Interface
RCA Audio Interface:	RCA Audio input/output Interface (Optional)
DC Power Plug:	DC Power Female Interface
General
Operating Conditions:	-10 °C ~ 60 °C
Operating Conditions:	Humidity 95% or less (non-condensing)
Power Supply:	12 V DC ± 10%/PoE(Optional)
Power Consumption:	12 VDC ± 10%, Max Power Comsumption Less than 8W (When the infrared lamps turn on)
Weight:	0.45KG

Q: When will you arrange the production?
A: We usually arrange the production immediately after receiving your Deposit payment.

Q: What is your accepted payment type?
A: Wire transfer, Paypal and Western Union; T/T advance 30% and balance when goods ready to ship.

Q: What logistic forwarder do you usually work with?
A: We work with EMS, TNT, UPS, FEDEX and other logistric forwarders. Assigned your own forwarder for shipment is available.

Q: What kinds of customization services Offered?
A: Logo/ Label/ Packing Box/ Manual/ Firmware

Q: Delivery time?
A: Usually 2-3weeks

Q: Warranty?
A: 18months for cam, 2year for Recorder

Q:What can you buy from us?
A:CCTV Camera,IP Camera system,Wifi Camera system,Analog Camera system,NVR DVR
CCTV Accessories：Power adapter, HDD(brand new and refurbish),Bracket etc; We can help to sourcing high quality with good price for all your enquirements.
